Riedel Communications, leading manufacturer of intercom, fiber, audio and radio technology, presented the new softwarebased Embedder/De-Embedder for MediorNet as well as the MediorNet Multi-I/O breakout panel and the optical video card at this year's NAB in Las Vegas, Nevada.
MediorNet Embedder/De-Embedder
The new Embedder/De-Embedder expands MediorNet's softwarebased conversion and signal processing features. The new tool embeds, deembeds and shuffles any AES3/EBU signal as well as other data formats, such as control data for cameras. Like other MediorNet features such as the Frame Synchronizer, the Test Pattern Generator or the Text/Graphic Inserter, this feature eliminates the need for additional outboard gear, resulting in a more compact and costeffective solution.
MediorNet Multi-I/O Breakout Panel
To offer a versatile solution for interfacing audio and other signals with MediorNet, the new MN-MBR Multi-I/O Breakout Panel provides eight AES and eight analog 4wire connectors over CAT-5. 12 GPIOs and four serial ports via Sub-D 9pin connectors complete the device's interfacing. All signals are distributed intelligently through the MediorNet installation. The 19"/1 RU panel is connected to the MediorNet frame via two 44 pin Sub-D connectors to the MediorNet MN-MIO Multiple I/O card, which occupies just one lowspeed port of the MediorNet mainframe. The breakout panel is also powered via the Multi-I/O card and does not need an external power supply.
MediorNet MN-HD4I-O / MNHD4O-O
Optical Video Cards The new MN-HD4I-O and MNHD4O-O cards provide four inputs or outputs with optical SFP connectors for four HD/SD-SDI/ ASI or two 3G-SDI video sources. The cards support all relevant video standards up to 1080p@60Hz. Each input operates independently and is equipped with auto format detection and onboard signal processing and conversion.
