(pressebox) (Karlsruhe, 01.06.2016) Piezo components from PI Ceramic are now immediately available as hemispheres or hollow spheres. The outside diameter is between 10 and 60 mm. Larger diameters are available on request. The minimum wall thickness is 1 mm and other dimensions are also possible on customer request.

Applications

Thanks to their design, the components are generally suitable for applications, which function as 360° sound transducers with a high bandwidth. Therefore, piezo components can be used in many different sonar application areas such as underwater communication, underwater monitoring, depth and underground relief measuring or for locating swarms of fish.

Application-Specific Adapted Design

The components are manufactured from ferroelectric soft or hard piezo materials according to the application range. This enables optimum setting with respect to the coupling factor and acoustic impedance. The spheres can be made with a hole or groove for easy mechanical integration.

Über Physik Instrumente (PI) SE & Co. KG: PI Ceramic is considered a global leading player in the field of piezo actuators and sensors. The broad range of expertise in the complex development and manufacturing process of functional ceramic components combined with state-of-the-art production equipment ensure high quality, flexibility and adherence to supply deadlines. Prototypes and small production runs of custom-engineered piezo components are available after short processing times. PI Ceramic also has the capacity to manufacture medium-sized to large series in automated lines. PI Ceramic, a subsidiary of Physik Instrumente (PI) GmbH & Co. KG, is located in the city of Lederhose, Thuringia, Germany.
